Microphone

CSF 450

Twin microphone cables for recording studios and installations

Especially when it comes to installations and outfitting of sound studios, many microphone cables have to be laid in cable ducts and wall bushings. The Cordial bulk cable CSF 450 features 2 microphone channels (2x 2 cores) in a common PVC jacket, thus ensuring space-saving installations (~ 6.4 mm diameter / bending radius ~ 33 mm). The wire pairs are protected against interferences and electrical fields by a tinned copper braid. The conductor cross-sections of 4x0.50mm² (AWG 21) provide an optimal signal transmission without "cutting off" high frequencies. The 64 tinned copper strands, each 0.10mm in diameter, ensure high flexibility, especially for fixed installations.

Also available with only one wire pair consisting of 2x 0.50mm² (CSF 250) or with 2x 0.75mm² (CSF 275) conductor cross sections.

Product information
Jacket PVC
Specifications
Technical facts
Conductor area 0.50 mm²
AWG AWG 21
Composition of conductor 64 x 0.10 mm
Material tinned copper
Conductor resistance 35 Ohm/km
Shielding tinned copper braided screen
Capacity cond.-cond. (pF/m) 180 pF/m
category Microphone
diameter 6.4 mm
weight 70 g/m
Conductor isolation PVC
Product variants
Colour Part number
CSF 450 BLACK 100
