Our 3-pin configuration DMX CPD FM 5-3 adapter features the conversion from 5-pin XLR female to 3-pin XLR male. The housings are made of black lacquered metal.
Light DMX
select
CPD FM 5-3
Product information
| cable | ||
| Jacket | PVC | |
| cable assign | FM_5-3 | |
| connector brand | NEUTRIK ® | |
| plugs |
1x XLR-female 5-pole
1x XLR male 3-pole
|
technical data
Technical facts
| Conductor area | 0.34 mm² |
| AWG | AWG 22 |
| Composition of conductor | 7 x 0.25 mm |
| Material | tinned copper |
| Conductor resistance | 56 Ohm/km |
| Shielding | tinned copper braided screen |
| Capacity cond.-cond. (pF/m) | 42 pF/m |
| category | Light DMX |
| diameter | 6.0 mm |
| weight bulk cable | 50 g/m |
| Conductor isolation | PE |
Lenghts & colours
| Colour | Length | Matchcode | item no. |
| 0.15 | CPD 0.15 FM 5-3 | 10937 |
