Our CPL LL 2 is a highly flexible 2 pin speaker cable to connect amps and passive speakers and is equipped with the tried-and-tested NEUTRIK® speakON plugs.
Loudspeaker
SELECT
CPL LL 2
Product information
| cable | CLS 225 |
| cable assign | LL2 |
| Brand | NEUTRIK |
| plug |
1 Speakon 2-pole
1 Speakon 2-pole
|
Specifications / Tender
| Type | Loudspeaker cable |
| Part no. | CLS 225 |
Mechanical data
| Conductor area | 2,5 mm² |
| Composition of conductor | 140 x 0,15 mm bare copper |
| Conductor isolation | PVC |
| Composition of cores | 2 cores |
| Screen | no screen |
| Overall jacket | PVC |
| Overall diameter | 7,8 ± 0,25 mm |
| Weight | 105 g/m |
| Working temperature | |
| mobile | (-5 °C) - (+70 °C) |
| fixed | (-20 °C) - (+70 °C) |
| min.Bending radius | |
| mobile | ~ 80 mm |
| fixed | ~ 40 mm |
| Thermal load | 0,31 kWh / m (~1,1 MJ / m) |
| Electrical data | |
| Conductor resistance | 8 Ω / km |
| Test Voltage | 2000 V eff. |
Product variants
| Colour | Part number |
| CPL 1.5 LL 2 | |
| CPL 3 LL 2 | |
| CPL 5 LL 2 | |
| CPL 10 LL 2 | |
| CPL 15 LL 2 | |
| CPL 20 LL 2 |
