Microphone
ESSENTIALS
CFM FM
Product information
| cable | CME 220 |
| cable assign | FM |
| Brand | REAN SILVER |
| plug |
1 XLR female 3-pole
1 XLR male 3-pole
|
Specifications / Tender
| Type | Microphone cable |
| Part no. | CME 220 |
Mechanical data
| Conductor area | 0,22 mm² |
| Composition of conductor | 28 x 0,10 mm bare copper |
| Conductor isolation | PE |
| Composition of cores | 2 twisted pairs |
| Screen | spiral wound copper wire screen |
| Overall jacket | PVC |
| Overall diameter | 5,8 ± 0,2 mm |
| Weight | 47 g/m |
| Working temperature | |
| mobile | (-5 °C) - (+70 °C) |
| fixed | (-20 °C) - (+70 °C) |
| min.Bending radius | |
| mobile | ~ 60 mm |
| fixed | ~ 30 mm |
| Electrical data | |
| Conductor resistance | <85 Ω / km |
| Capacity (cond./cond.) | 95 pF / m |
| Capacity (cond./screen) | 190 pF / m |
| Test Voltage | 500 V eff. |
Product variants
| Colour | Part number |
| CFM 0.5 FM | |
| CFM 1 FM | |
| CFM 1.5 FM | |
| CFM 2.5 FM | |
| CFM 5 FM | |
| CFM 7.5 FM | |
| CFM 10 FM | |
| CFM 20 FM |
